Features

The heart of the SRS-X1000, featuring:
• Enhanced Heat Dissipation: A 3mm-thick front aluminum panel and a larger aluminium extrusion case for effective heat management. alumi-

num case for effective heat management.
• High-Grade Connectivity: RCA pin jacks and a 3mm-thick front aluminum panel ensure a pristine connection.

• Low Noise FET: Selected for the First Stage amplifier, paired with a refined emitter follower circuit in the Output Stage for unparalleled

clarity.
• Compact Chassis: Easy for placement, transportability and aesthetic appeal

Specification

• Frequency response: DC to 35,000Hz/+0, -3dB

• Harmonic distortion: 0.01% or less/1kHz 100V r.m.s.

• Amplification: 58dB (800 times)

• Maximum output voltage: 280V r.m.s./1kHz

• Input impedance: 25kΩ

• Input terminals: RCA x 1

• Output terminal: Parallel out x 1

• Bias voltage: 580V DC

• Power supply: AC adaptor included

• Power consumption: 12VDC/500mA

• External dimensions: 132(W)×38(H)×153(D)mm (excluding protruding

parts)

• Weight: 540g
